  Fixing Notes

THRU-JOIST

TJ140, TJ190, TJ240 and TJ290


  1. Bracket needs to be installed firmly up against under side of joist and all holes nailed off before drilling service duct hole.
  2. Galv Bracket 30mm x 3.15 dia hot dip galvanised nails to be used in NZ.
  3. Galv Bracket 35mm x 3.15 dia hot dip galvanised nails to be used in Australia.
  4. Nail ALL holes.
  5. Maximum hole cut is 121mm dia in 190mm, 240 and 290mm THRU-JOIST™ or 68mm dia in 140mm THRU-JOIST™ brackets.
  6. Use TJ140 on 140mm joist, TJ190 on 190mm, TJ240 on 240mm and TJ 290 on the 290mm joist.
  7. Obtain fall for plumbing pipes by drilling holes at varying heights, within drilling circle, on adjacent joists.
  8. No limitation on where THRU-JOIST™ brackets may be installed along the length of joist.
  9. Use of multiple brackets on one joist must have minimum of 1500mm spacing between centres.
  10. NOT TO BE USED IN EXTERIOR OR SUB FLOOR SITUATIONS.
  11. Nails are not provided.
  12. The purchaser is responsible for checking that THRU-JOIST™ brackets are suitable for there intended use.


THRU-JOIST DOUBLE

TJD140, TJD190, TJD240 & TJD290


  1. Bracket needs to be installed firmly up against under side of joist and all holes nailed off before drilling service duct hole.
  2. Galv Bracket 30mm x 3.15 dia hot dip galvanised nails to be used in NZ.
  3. Galv Bracket 35mm x 3.15 dia hot dip galvanised nails to be used in Australia.
  4. Nail ALL holes.
  5. Maximum hole cut is 121mm dia in 190mm, 240 and 290mm THRU-JOIST or 68mm dia in 140mm THRU JOISTbrackets.
  6. Use TJD140 on 140mm joist, TJD190 on 190mm, TJD240 on 240mm and TJ D290 on the 290mm joist.
  7. Obtain fall for plumbing pipes by drilling holes at varying heights, within drilling circle, on adjacent joists.
  8. No limitation on where THRU-JOIST brackets may be installed along the length of joist.
  9. Use of multiple brackets on one joist must have minimum of 1500mm spacing between centres.
  10. NOT TO BE USED IN EXTERIOR OR SUB FLOOR SITUATIONS.
  11. Nails are not provided.
  12. The purchaser is responsible for checking that THRU-JOIST??brackets are suitable for its intended use.


THRU TOP PLATE

TTP


  1. Bracket needs to be installed firmly up against the underside of the
  2. TOP PLATE™ and all holes screwed off before drilling service duct hole.
  3. 12g x 35mm hot dip galvanised screws are provided and must be used in NZ.
  4. 12g x 35mm hot dip galvanised screws are provided and must be used in Australia.
  5. Screw ALL holes.
  6. Maximum hole cut is 59mm dia. in 90mm x 45mm top plate when using THRU-TOP PLATE™ brackets.
  7. Use TTP on 90mm x 45mm top plate.
  8. In extra high wind zone only. Install a 90 x 45 packer under the top plate between the studs.
  9. Install bracket then drill through both packer and top plate.
  10. No limitation on where THRU-TOP PLATE™ brackets may be installed along the length of top plate.
  11. No limitation on number that can be used along the length of top plate.
  12. NOT TO BE USED IN EXTERIOR APPLICATIONS.
  13. The purchaser is responsible for checking that THRU-TOP PLATE™ brackets are suitable for its intended use.


THRU TOP PLATE Electrical

TTPE


  1. Bracket needs to be installed firmly up against the underside of the top plate and all holes screwed off before drilling service duct hole.
  2. 12g x 35mm hot dip galvanised screws are provided and must be used in NZ.
  3. 12g x 35mm hot dip galvanised screws are provided and must be used in Australia.
  4. Screw ALL holes.
  5. Maximum hole cut is 190mm x 30mm in 90mm x 45mm top plate when using THRU-TOP PLATE E™ brackets.
  6. Use TTPE on 90mm x 45mm top plate.
  7. No limitation on where THRU-TOP PLATE E™ brackets may be installed along the length of top plate.
  8. No limitation on number that can be used along the length of top plate.
  9. NOT TO BE USED IN EXTERIOR APPLICATIONS.
  10. The purchaser is responsible for checking that THRU-TOP PLATE E™ brackets are suitable for its intended use.


THRU STUD

TS90


  1. Bracket needs to be installed firmly up against stud and all holes nailed off before drilling service duct hole.
  2. Galv. Bracket 30mm x 3.15 dia hot dip galvanised nails to be used in NZ.
  3. Galv. Bracket 35mm x 3.15 dia hot dip galvanised nails to be used in Australia.
  4. Nail ALL holes.
  5. Maximum hole cut is 59mm dia. in 90mm X 45mm stud when using THRU-STUD™ brackets.
  6. Use TS90 on 90mm x 45mm wall studs.
  7. No limitation on where THRU-STUD™ brackets may be installed along the length of stud.
  8. No restriction on number of THRU-STUDTM brackets per stud.
  9. THRU-STUDTM can be used on any stud length that complies with the NZS3604 or AS1684.2-2011.
  10. NOT TO BE USED IN EXTERIOR OR SUB FLOOR SITUATIONS.
  11. Nails are not provided.
  12. The purchaser is responsible for checking that THRU-STUD™ brackets are suitable for its intended use.
